齒數(shù)

鏈輪型號

QD套型號

外圓直徑

主要尺寸

參考重量

PDF圖紙

DXF圖紙

De

Dp

L1

L2

C

Y

G

X

B1

鏈輪

QD套

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

Lbs

36

LD40-3A36T-SK

SK

6.020

5.737

2  5/8

2 1/8

2 1/8

3 7/8

19/32

1 1/4

11/40

1.407

8.160

6.16

請咨詢

請咨詢

45

LD40-3A45T-SK

SK

6.970

6.691

2  5/8

2 1/8

2 1/8

3 7/8

19/32

1 1/4

11/40

1.407

11.920

9.52

48

LD40-3A48T-SK

SK

7.930

7.645

2  5/8

2 1/8

2 1/8

3 7/8

19/32

1 1/4

11/40

1.407

15.130

13.16

52

LD40-3A52T-SK

SK

8.570

8.281

2  5/8

2 1/8

2 1/8

3 7/8

19/32

1 1/4

11/40

1.407

18.080

16.08

60

LD40-3A60T-SK

SK

9.840

9.554

2  5/8

2 1/8

2 1/8

3 7/8

19/32

1 1/4

11/40

1.407

24.600

22.60

68

LD40-3A68T-SF

SF

11.120

10.826

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

31.980

29.98

72

LD40-3A72T-SF

SF

11.750

11.463

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

37.400

34.40

76

LD40-3A76T-SF

SF

12.390

12.099

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

51.920

48.92

84

LD40-3A84T-SF

SF

13.660

13.372

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

56.700

53.78

95

LD40-3A95T-SF

SF

15.410

15.122

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

58.940

55.94

102

LD40-3A102T-SF

SF

16.530

16.236

2 15/16

2 1/4

2 1/4

4 5/8

19/32

1 1/4

11/40

1.407

62.240

59.24
