同步帶輪型號

類型

錐套
型號

齒數(shù)

外圓

直徑

節(jié)距圓

直徑

擋圈

直徑

輪轂

直徑

Di

E

M

L

F

K

參考

重量

Dp

De

Df

Dm

inch

inch

inch

inch

inch

inch

inch

inch

inch

inch

lbs

14M40-SK28T-F

1EF

SK

28

4.912

4.808

5  9/16

-

3 1/8

7/8

5/8

1 7/8

2 1/8

-

5.5

14M40-SK29T-F

1EF

SK

29

5.088

4.983

5  9/16

-

3 1/8

7/8

5/8

1 7/8

2 1/8

-

6.5

14M40-SK30T-F

1DF

SK

30

5.263

5.153

6 1/8

-

3 15/16

3/16

7/16

1 7/8

2 1/8

7/16

7.0

14M40-SK32T-F

1DF

SK

32

5.614

5.504

6 1/8

-

3 15/16

3/16

7/16

1 7/8

2 1/8

7/16

8.0

14M40-SK34T-F

1DF

SK

34

5.965

5.858

6 1/2

-

4  1/16

3/16

7/16

1 7/8

2 1/8

7/16

8.5

14M40-SF36T-F

1DF

SF

36

6.316

6.206

6 13/16

-

4 11/16

3/16

5/16

2

2 1/8

7/16

9.5

14M40-SF38T-F

1DF

SF

38

6.667

6.557

7  3/16

-

4 15/16

3/16

5/16

2

2 1/8

7/16

11.5

14M40-SF40T-F

1DF

SF

40

7.018

6.909

7 1/2

-

5  1/16

3/16

5/16

2

2 1/8

7/16

13.0

14M40-E44T-F

1DF

E

44

7.720

7.610

8  7/32

-

6 1/8

5/8

1/8

2 5/8

2 1/8

1/4

16.5

14M40-E48T-F

1DF

E

48

8.421

8.311

8 7/8

-

6 1/2

5/8

1/8

2 5/8

2 1/8

1/4

20.0

14M40-E52TE

1DF

E

52

9.123

9.013

9 11/16

-

7  3/16

5/8

1/8

2 5/8

2 1/8

1/4

24.0

14M40-E56T-F

1DF

E

56

9.825

9.715

10 3/8

-

7 7/8

5/8

7/8

2 5/8

2 1/8

1/4

28.0

14M40-E60T-F

1DF

E

60

10.527

10.417

11  1/16

-

8 1/2

5/8

1/8

2 5/8

2 1/8

1/4

29.0

14M40-E64T-F

2DF

E

64

11.229

11.119

11 3/4

6 1/4

9 1/4

5/8

1/8

2 5/8

2 1/8

1/4

31.0

14M40-E68T-F

2DF

E

68

11.930

11.820

12 1/2

6 1/4

10

5/8

1/8

2 5/8

2 1/8

1/4

32.0

14M40-E72T-F

2DF

E

72

12.632

12.522

13  3/16

6 1/4

10 11/16

5/8

1/8

2 5/8

2 1/8

1/4

33.0

14M40-E80T-F

2DF

E

80

14.036

13.926

14 5/8

6 1/4

12 1/8

5/8

1/8

2 5/8

2 1/8

1/4

38.0

14M40-E90T

3D

E

90

15.790

15.680

-

6 1/4

14

5/8

1/8

2 5/8

2 1/8

1/4

39.0

14M40-E112T

3D

E

112

19.650

19.540

-

6 1/4

17 13/16

5/8

1/8

2 5/8

2 1/8

1/4

51.0

14M40-E144T

3D

E

144

25.264

25.154

-

6 1/4

23 3/8

5/8

1/8

2 5/8

2 1/8

1/4

80.0
